Bearing Number | Boundary dimensions(mm) | Mass | |||||||
SNBAL | d | D | B | C | dk |
rs
min
|
r1s
min
|
α°
≈
|
Kg
≈
|
GEC320XS 2RS | 320 | 440 | 160 | 135 | 380 | 1.1 | 3 | 4 | 77 |
GEC340XS 2RS | 340 | 460 | 160 | 135 | 400 | 1.1 | 3 | 3 | 82 |
GEC360XS 2RS | 360 | 480 | 160 | 135 | 420 | 1.1 | 3 | 3 | 88 |
GEC380XS 2RS | 380 | 520 | 190 | 160 | 450 | 1.5 | 4 | 4 | 127 |
GEC400XS 2RS | 400 | 540 | 190 | 160 | 470 | 1.5 | 4 | 3 | 132 |
GEC420XS 2RS | 420 | 560 | 190 | 160 | 490 | 1.5 | 4 | 3 | 145 |
