Bearing Number | Boundary dimensions(mm) | Mass | ||||||||
SNBAL | d | D | B | C |
d1 max |
dk |
rs min |
r1s min |
α° ≈ |
Kg ≈ |
GEWZ12ES | 12.7 | 22.225 | 19.05 | 9.525 | 15.875 | 18 | 0.15 | 0.6 | 5 | 0.024 |
GEWZ15ES | 15.875 | 26.988 | 23.8 | 11.913 | 19.812 | 23 | 0.15 | 0.6 | 5 | 0.038 |
GEWZ19ES | 19.05 | 31.75 | 28.575 | 14.275 | 23.368 | 27.5 | 0.3 | 0.6 | 5 | 0.064 |
GEWZ22ES | 22.225 | 36.513 | 33.325 | 16.662 | 27.178 | 32 | 0.3 | 0.6 | 5 | 0.098 |
GEWZ25ES | 25.4 | 41.275 | 38.1 | 19.05 | 30.988 | 36.5 | 0.3 | 0.6 | 5 | 0.142 |
GEWZ31ES | 31.75 | 50.8 | 47.625 | 23.8 | 38.735 | 45.5 | 0.6 | 0.6 | 5 | 0.271 |
GEWZ34ES | 34.925 | 55.563 | 52.375 | 26.187 | 42.418 | 49 | 0.6 | 1 | 5 | 0.373 |
GEWZ38ES | 38.1 | 61.913 | 57.15 | 28.575 | 46.99 | 54.7 | 0.6 | 1 | 5 | 0.494 |
GEWZ44ES | 44.45 | 71.438 | 66.675 | 33.325 | 54.991 | 63.9 | 0.6 | 1 | 5 | 0.762 |
GEWZ50ES | 50.8 | 80.963 | 76.2 | 38.1 | 62.484 | 73 | 0.6 | 1 | 5 | 1.11 |
GEWZ57ES | 57.15 | 90.488 | 85.725 | 42.85 | 70.104 | 82 | 0.6 | 1 | 5 | 1.57 |
GEWZ63ES | 63.5 | 100.013 | 95.25 | 47.625 | 77.724 | 92 | 1 | 1 | 5 | 2.15 |
GEWZ69ES | 69.85 | 111.125 | 104.775 | 52.375 | 85.852 | 100 | 1 | 1 | 5 | 2.9 |
GEWZ76ES | 76.2 | 120.65 | 114.3 | 57.15 | 93.345 | 109.5 | 1 | 1 | 5 | 3.59 |
GEWZ82ES | 82.55 | 130.175 | 123.825 | 61.9 | 101.219 | 119 | 1 | 1 | 5 | 4.69 |
GEWZ88ES | 88.9 | 139.7 | 133.35 | 66.675 | 109.22 | 128 | 1 | 1 | 5 | 5.86 |
GEWZ95ES | 95.25 | 149.225 | 142.875 | 71.425 | 116.586 | 137 | 1 | 1 | 5 | 7.11 |
GEWZ101ES | 101.6 | 158.75 | 152.4 | 76.2 | 124.587 | 146 | 1 | 1 | 5 | 8.56 |
GEWZ114ES | 114.3 | 177.8 | 171.45 | 85.725 | 140.335 | 164.5 | 1 | 1 | 5 | 12.24 |
GEWZ127ES | 127 | 196.85 | 190.5 | 95.25 | 155.705 | 183 | 1 | 1 | 5 | 16.63 |
GEWZ152ES | 152.4 | 222.25 | 209.55 | 104.775 | 178.308 | 207 | 1 | 1 | 5 | 20.7 |
